Plastic Fruit Box Making Machine, Plastic Food Container Making Machine, Plastic Jar Making Machine

FOB Reference Price:Get Latest Price
$19,000.00 - $27,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
TVD-2L
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
Bottle
Plastic Processed:
PE
Place of Origin:
Zhejiang, China
Brand Name:
TONVA
Voltage:
380V
Dimension(L*W*H):
2.9*1.9*1.8
Certification:
ISO9001;BV;CE;SGS
Warranty:
1 Year
Raw Material:
PE/PP/PA/PVC etc
Working Stations:
double
Product range:
3ml - 2L
Clamping Force:
50KN
Clamping:
pneumatic
Parison Controller:
Optional
View-stripe:
Optional
Multilayer:
Optional
Blow Moulding Type:
Extrusion Blow Moulding
Automatic:
Yes
After-sales Service Provided:
Engineers available to service machinery overseas
Power(W):
15kW
Weight:
3200kg
Supply Ability
Supply Ability:
35 Set/Sets per Month
Packaging & Delivery
Packaging Details
Film packaging or wood packaging usually
Port
Ningbo
Company Profile
Configuration
PLC control Program
MITSUBISHI
JAPAN
HMI(Human Machine Interface)
MITSUBISHI
JAPAN
Pneumatic Cylinder
AIRTAC
TAIWAN
Electrical Parts
SCHNEIDER
FRANCE
Air / Button Switch
SCHNEIDER
FRANCE
Solenoid Valve
MINDMAN
TAIWAN

Brief Introduction:

1) Smart series double station blow molding machine is TONVA company's original design,it's combines bydraulic and pneumatic.

2) The performance is well and running stable,it's easy to operater.The sal;es is hundreds and it's mature design in company.

3) Suitable from 5ml to 5L.

4) Suitable for drug bottle,washing bottle,oil bottle,plastic toy,beverage bottle,drill box etc.

Specification
TVD-2L Technical Parameter
CATEGORY
ITEM
UNIT
TVD-2L


Basic Specification
Raw Material
--
PE/PP/PA/PVC etc
Dimension
m
2.9*1.9*1.8
Total Weight
kg
3200




Extrusion System
Diameter of screw
mm
65
Screw L/D ration
L/D
25:1
Plasticizing capacity
kg/h
70
Number of heating zones
pcs
5
Extruder heating power
kw
15
Extruder drive power
kw
15


Die Head
Number of heating zones
pcs
2
Heating power
kw
4
Number of head
cavity
1-4


Clamping System
Clamping range
mm
150
Sliding Distance
mm
360
Clamping force
kn
50




Power Consumption
Air pressure
Mpa
0.6
Air consumption
m3/min
0.8
Cooling water pressure
Mpa
0.3
Cooling water consumtion
m³/h
1.0
Total Power
KW
34
Average power consumption
KW
15
Our Service

1,Instruction for Installation and Debugging:


Before delivery, TONVA takes responsiblity for debugging of machine, in order to make sure provided machine could be safely and smoothly put into operation.

TONVA also take responsiblity to have debugging overseas, and clients aborad please first send invitation,then provide our engineer with round-trip tickets,accommodation,vehicle and USD80 per day for salary.


2,User Training:

Before delivery,TONVA will take responsibility to indoctrinate technical training to the users so that they could understand machines' features and could operate the machine by themselves.

3,Warranty Period:

The waranty period for TONVA machine is one year with a life long maintenance. If the user requires special quality guarantee, other stipulated warranty period may be made after mutual agreement.
