3cavities 1L extrusion blow molding machine making PP bottle

FOB Reference Price:Get Latest Price
US $19,700-31,000 / Sets | 1 Set/Sets (Min. Order)
Model Number:
TVD-1L
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
Bottle
Plastic Processed:
PE/PP/PA/PVC etc.
Blow Moulding Type:
Extrusion Blow Moulding
Automatic:
Yes
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
TONVA
Voltage:
380V
Power(W):
7.5kW
Dimension(L*W*H):
2.6*1.6*1.8
Weight:
2300kg
Certification:
CE SGS ISO
Warranty:
1 Year Guarantee
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
400 Set/Sets per Year
Packaging & Delivery
Packaging Details
film packing
Port
Ningbo
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(day) 55 To be negotiated
Company Information

TONVA PLASTICS MACHINE CO.,LTDfactoryD

    TONVA company was established at 1993. The company is one of the largest manufactures of Extrusion Blow Molding Machine, Stretch blow molding machine and molds in China.



    The Company has a group of experienced people who contribute more than twenty years in Blow Molding Machine industry and a team who good at after-sale service. We have got the certificate of ISO9001:2008 International Quality Control System and the CE&SGS system. Moreover, since the company focus on innovation and invest in the advanced technology year after year, it been named the National High-Tech Enterprise in the year of 2014. With fabulous reputation and favorable service, our products reach great sales both in domestic market and more than 80 countries.



    TONVA Extrusion Blow Molding Machine can be divided into Smart series, Standard series, Accumulator type large series. The range of the capacity is from 3ml to 3000L. They are suitable for Various materials, as PE,PP,PVC,PS,EVOH,EVA etc. They are used to produce various kinds of plastic products, such as oil barrel,Sprayer barrel,cosmetics bottle,pharmaceuticals bottle,food package,plastic toys,Christmas ball,plastic experimental apparatus and auto-parts etc.



    Based on different functions, TONVA Extrusion Blow Molding Machine has various of function for clients products optional: such as Parison controller for bottle area wall thickness control, Co-extrusion of multiple layers, view line strip device, up&down device, filter, deflashing device and servo system.



Product Description



TVD-1L





Smart series double station blow molding machine is TONVA company's original design,it's pneumatic.

The perfomance is well and running stable,it's easy to operate.The sales is hundreds and it's a mature design in company.This machine is suitbale from 5ml to 1L,shuitble for drug bottle,washing bottle,oil bottle,chemical bottle,plastic toy,beverage bottle,drill box ect.



Specifications

26-year manufacturer of blow molding machine
Famous brand component parts
CE; ISO;SGS
1-year warranty
Customized

Main Characteristic:



 (1) Double stations,single layer,55mm screw7.5kw motor,for PE/PP/PVC/PA material;

(2) Die-heads for choosing:

single die-head (<= 1L): 1L---around 400bottles per hour;

double die-heads(<=500ml): 500ml---around 1000 bottles per hour;

triple die-heads(<=300ml): 300ml---around 1500 bottles per hour;

four die-heads(up to 50ml): 50ml---around 2800 bottles per hour;

(3) Center Distance:

four die-heads---60mm; triple die-heads---80mm; double die-heads---120mm;

(4) Clamping by pneumatic system;

(5) Deflashing system: Neck/Handle/Bottom trimming;

(6) Power supply: 380VAC,50HZ. (depending on clients' country);



Finished bottle show

PP PINGZI.JPGppppp.JPG

Auxiliary Machine



Our Services

1. Instruction for Installation and Debugging:

Before delivery,TONVA is responsible for debugging of machines,to make sure the provided machine could safely and smoothly put into operation;

TONVA also takes responsibility to have debugging overseas,and clients abroad please send invitation to engineer of TONVA in advance,provides the engineer with round-trip tickets,accommodation,vehicle and USD100 per day for salary.
2. User Training:

Before delivery,TONVA will take responsibility to indoctrinate technical training to the users so that they could understand the machine features and could operate the machine by themselves.

3. Warranty Period:

The warranty period for TONVA machine is one year with a life-long maintenance.Other stipulated warranty could be made if clients require special quality guarantee.

Note:Above information is only for reference,the product can be customized based on different requirements.
