extrusion 220L plastic drum blow molding machine

FOB Reference Price:Get Latest Price
US $43,800-80,000 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
Bottle
Plastic Processed:
PE
Blow Moulding Type:
Extrusion Blow Moulding
Automatic:
Yes
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
TONVA
Model Number:
TVA-220L
Voltage:
depend on client's country
Power(W):
80kw
Dimension(L*W*H):
6.2*3.6*5.3
Weight:
22T
Certification:
CE, ISO9001:2008,SGS
Warranty:
1 YEAR warranty
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
30 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Film packaging & wood packaging usually.
Port
ningbo
Lead Time :
within 40 days after receiving the deposit.



TVA-220L plastic drum blow molding machine Products display:

    50L





Tonva plastic drum blow molding machine Extrusion machine Main Characteristic:



 1.. Power supply: 380VAC, 50Hz (depending on client's country).



2.. This series is applicable for PP,PE,PS raw material, and volume between 20L-60L, it is widely used in plastic barrel, tool boxes, hollow desk board, chairs, auto parts and other large and medium-sized plastic hollow products.

Adopts two pull-rod type  closing-mold device by rack and pinion system. The large setting platen is suitable for various sizes of moulds.

Adopts accumulator die head, with high quality nitrogen treatment and hardness of surface, resulting smooth flow and quick parison ejection.

Based on products, equip with 30 points or 100 points standard parison controller, to control the thickness of parison precisely.





Plastic drum blow molding machine Basic working theory:

This kind of blow molding machine is using PLC control system, operating manual in English, pneumatic operated, clamping by hydraulic cylinders actuated by pneumatic primary cylinders. Moreover, it equips with deflashing system, resulting in saving time and manual cost for clients.





Our machine adopts famous brand in most component parts, almost from GERMANY, JAPAN, FRANCE, TAIWAN



732467190_024



220 litre plastic drum blow molding machine Technical parameters:



Item

Spec.

Standard specifications

Basic Spec.

Applicable Raw Material

PE/PP

Max Container Capacity

220L

Dimension (L*W*H)

6.2× 3.6× 5.3m

Total Weight

22ton

Extrusion system

Main (driving) screw

Φ120mm

Screw ratio

30:1

Barrel screw

38CRMOALA

MAX extruder output

220KG/H

Driving mode

Motor, gear case, belt transmission

Drive motor

110KW

Screw speed

10-50rpm

Adjust of Up and Down

yes

Temperature Control

5

Heating power

26KW

Cooling  fan

5

Cooling system

yes

Clamping System

Clamping direct

2 tie

MAX locking plate spacing

900*1450mm

Mold open spacing

1600mm

Clamping force

600KN

Max Mould thickness

800MM

Mould fixed form

Clamping cap

Stroke  control

Proximity switch



Die head

Die head material

38CRMOALA

Accumulator volume

23L

Heating power

30kw

Parison thickness adjust

MOOG WALL THINKNESS CONTRAL SYSTEM

Injection stroke control

yes

Down-shot unit

Blowing needle stroke control

Inductive switch

Blowing needle to support the material

Yes

Blowing needle position adjustment

Yes

Drive mode

Hydraulic motor

Robot

Lead control

Pillar

Temperature control

Water

Overload protection

Yes

Control action

PLC

Machine control

Man-machine operating interface

Oil hydraulic system

Motor

30KW

Directional control

Reversing valve

Maximum pressure rating

100Kg/cm2

Directional control

Reversing valve

Power Consumption

Total Power

150KW

Average Power Consumption

80KW





Plastic drum blow molding machine After-sale service:



average1. Instruction for Installation and Debugging



Before delivery, TONVA takes responsible for debugging of machine, in order to make sure the provided machine could be safely and smoothly put into operation.



TONVA also take responsibility to have debugging overseas, and Client abroad please sends invitation forward of time to engineer of TONVA, provides the engineer with round-trip tickets, accommodation, vehicle and $40 per day salary.





 User Training



Before delivery, TONVA will take responsibility to indoctrinate technical training to the users so that they could understand the machine features and could operate the machine by themselves.



 Warranty Period



The warranty period for TONVA machine is one year with a life long maintenance. If the user requires special quality guarantee, other stipulated warranty period may be made after mutual agreement.

.jpg



More details of extrusion machine ,please feel free to contact us!
